Description
In top hammer drilling, the shank adapter transmits impact energy from the piston to the rod(s) or tube(s). Additionally, rotation torque is delivered via the shank adapter.
|
Product Name: |
High Quality and china factory! shank adapter |
|
Description: |
High Quality and china factory! shank adapter drills Shank adaptor is used for transmitting power between drill machine and drill stems |
|
MOQ: |
1 Piece for testing and trial order |
|
Thread: |
R32,R38,T38,T45,T51 |
|
Length: |
300mm-800mm |
|
our shank adaptors are available for : |
World top brand(COP1238,COP1838,COP1032 etc) |
|
Furukawa (HD715,HD612,HD609,PD200 etc) |
|
|
Ingersoll-Rand (VL140,VL671,YH80A etc) |
|
|
Tamrock(HLX5,HL600,HL500,HL300,HL700,HL850,HL1000,HL1500 etc) |
• Underground mining
• Tunneling,quarrying
Specification of shank adapter
|
Part Number |
Product Code and Brief Description |
Thread |
Length (mm) |
Weight (kg) |
|
4148301077 |
COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME [G1] |
R32 |
435 |
3.9 |
|
4148301078 |
COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME [G2] |
R38 |
435 |
4.2 |
|
4148301079 |
COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME [G3] |
T38 |
435 |
4.2 |
|
4148301080 |
COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME [G4] |
R32 |
525 |
4.8 |
|
4148301081 |
COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME [G5] |
T38 |
r
525 r |
r
5 r |
